Garmin GPSMAP 8000 Series Range GPSMAP 8000 large-format multifunction display features a full HD screen with touch control. Sunlight-readable, anti-glare display is exceptionally easy to view and also includes auto-dimming feature for use in low light or at night. New maximum glass design enables you to experience a beautifully powerful, completely networked helm at your fingertips.
In-plane switching (IPS) LCD display — an industry first for this class — provides consistent, accurate colors from all viewing angles. It also provides standard USB touch output for use as a touchscreen monitor for Windows® and Mac® operating systems. Install multiple displays with the industry’s lowest flush-mount profile or flat mount them edge-to-edge to create a sleek glass helm look. Quick, 1-touch access to the information you need makes boating easier.
- Premium 17-inch full HD display with pinch-to-zoom touchscreen control has highest resolution on the marine market
- Configure the full system to provide 1-touch setting access for docking, cruising, fishing, anchoring and more
- Beautiful glass helm look with ability to install multiple displays either flush or flat mounted edge-to-edge
- High-performance processor delivers our fastest map drawing ever and enhanced video processing
- Provides a superior user experience across your entire network for radar, sonar and multimedia
Features
- Full System Integration
- New High-performance Processor
- Customize Layouts with SmartMode™ Control
- Garmin Marine Network and NMEA 2000® Network Support
- Network Sharing
- SailAssist Features
Garmin GPSMAP 8000 Series Range Specifications
General |
|
| Physical dimensions | 16.5″” x 12.1″” x 2.8″” (41.9 cm x 30.7 cm x 7.1 cm) |
|---|---|
| Weight | 11.48 lbs (5.21 kg) |
| Water rating | IPX7 |
| Display type | Touchscreen IPS display (anti-glare finish) |
| Display size | 14.4″” x 9.1″” (36.6 x 23.1 cm) |
| Display resolution | 1920 x 1200 pixels |
| Power consumption | Max power usage at 10 Vdc: 40 W
Typical current draw at 12 Vdc: 2.8 A Max current draw at 12 Vdc: 3.5 A |
| Antenna | External only |
| Mounting options | Flush or Flat |
| Receiver | 10 Hz high-sensitivity |
| Garmin Marine Network™ ports | 4 |
Maps & Memory |
|
| Accepts data cards | 2 SD Cards (with Garmin SD card reader accessory) |
|---|---|
| Waypoints | 5,000 |
| Routes | 100 (250 waypoints each) |
| Track log | 50,000 points; 50 saved tracks, with 5000 points each |
| Preloaded maps | None |
Sonar Features & Specifications |
|
| Dual-frequency (50/200 kHz) sonar capable | Yes (with external black box, sold separately) |
|---|---|
| Dual-beam (77/200 kHz) sonar capable | Yes (with external black box, sold separately) |
| CHIRP sonar technology | Yes (with external black box, sold separately) |
| ClearVü | Yes (with GCV™ black box, sold separately) |
| SideVü | Yes (with GCV™ black box, sold separately) |
