Zipwake Dynamic Trim-Control System Presenting Zipwake, the new, Dynamic Trim-Control System that’s set to revolutionize the boat world. Featuring an advanced, intuitive control system and a stunning new innovative design, Zipwake delivers a more comfortable ride, better performance and improved fuel consumption.
The world’s first inexpensive dynamic trim-control system, incorporates a state-of-the-art family of durable, fast-acting interceptors. The system is fully automatic. It significantly enhances the boat’s performance, fuel economy, comfort and safety when accelerating, turning or running in a seaway.
Zipwake’s stylish control panel is carefully designed to be user-friendly and intuitive to allow the driver to focus on the right thing – enjoying the boat ride!
The panel’s two unique control wheels provide easy, quick and intuitive manual control of running trim, heel or heading. However, the system normally operates in automatic control mode, which is enabled by a single press on the AUTO button. In this mode, the built-in high-frequency GPS, 3D gyro sensors and robust motion controller automatically ensure dynamic elimination of un- comfortable and dangerous boat pitch and roll. Features
- Automatically minimizes wave resistance and saves fuel.
- Built-in quality, simplicity and easy expansion, yet still affordable.
- Fully automatic
- Dynamic pitch and roll control
- Steering enhancement
- Built-in GPS and motion sensors
- Unique and intuitive 3D controls
- Sunlight readable colour display
- Instant state user feedback
- Auto power on/off via ignition key sense
Zipwake Dynamic Trim-Control System Specifications
Model: CP-S
Display: 2.4’’ Transflective color TFT, 320 x 240 pixels, double-sided, anti-reflection coated window
Internal sensors: 5 Hz GPS, 3D Gyro, 3D Accelerometer, Ambient light
Supply Voltage: 12 – 32 V DC
Power Consumption: 10 W max
Operating Temperature: -20° to +85°C (-4° to +185°F)
Storage Temperature: -40° to +90°C (-40° to +194°F)
Waterproof Rating: IP67 / IP64 (front / back)
Compass Safe distance: 0.5 m (1.7 ft)
Compliance: CE, FCC
Weight: 0.22 kg (0.49 lbs)
Mounting: Flush or surface
