Description
Combining a high-performance visible marine camera with long-range optical zoom capability, the M300C offers positive target identification for law enforcement, commercial, and recreational applications. Advanced gyro-stabilization provides steady imaging in rough sea conditions and allows the M300C to monitor targets or hazards over long distances continuously. Exceptional low light performance from the M300C gives captains enhanced awareness once the sun dips below the horizon.
Features
- Better than binoculars, the M300C with 30x optical zoom and image stabilization delivers superior long-range imaging and positive target identification
- Ultra-low light camera technology provides visible imagery in the most challenging lighting conditions
- Two-axis mechanical stabilization virtually eliminates the effects of pitch, heave, and yaw
- Electronic stabilization minimizes low frequency rumble and vibration
- Optional joystick control unit and integration with multifunction navigation displays
- ONVIF-compliant for PTZ security camera functionality
FLIR M300C Pan & Tilt Camera with 30X Optical Zoom Specifications
- Detector Type: 1/2.8” Exmor R CMOS
- Lines of Resolution: High Definition up to 1080/30p
- Minimum Illumination: 0.1 lux (50 IRE, 1/30s, ICR off, slow shutter off, high sensitivity off) / 0.0008 lux (30 IRE, ICR on, slow shutter 1/4s, high sensitivity on)
- Zoom: 30× Optical Zoom
- E-Zoom: 12x
- Focal Length: 129 mm to 4.3 mm
- Field of View: Optical 63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
- Gyro Stabilized: Yes
- ClearCruise AR: Yes, with Raymarine Axiom
- Pan/Tilt Adjustment Range: 360° Continuous Pan, +/- 90° Tilt
- Analog Video Output: NTSC
- Analog Video Connector Types: BNC
- Network Video Output: Single H.264 IP Network Video Stream
- HD-SDI Lossless Video Output: Yes
- Power Requirements: 12 to 24 VDC
- Power Consumption: 41 W typical, 56 W typical (with heaters on.) Note: FLIR recommends using a 75 W power supply
- Operating Temperature Range: -13°F to +131°F (-25°C to +55°C)
- Storage Temperature Range: -30°F to +158°F (-30°C to +70°C)
- Automatic Window Defrost: Standard at Power-Up
- Sand/Dust Ingress: Mil-Std-810E or IP6X
- Water Ingress: IPX6 (heavy seas, power jets of water)
- Shock: 15g vertical, 9g horizontal
- Vibration: IEC60945
- Lightning Protection: Standard
- Salt Mist: IEC60945
- Wind: 100 knots (115.2 MPH)
- EMI: IEC60945
- Weight: 6.3 kg (13.9 lb ) without mounting riser; 6.75 kg (14.9 lb) with mounting riser.
- Size: Camera: Base diameter: 222.2 mm (8.7 in.) Height: 328.3 mm (12.9 in.) Camera attached to mounting riser: Base diameter (with seal): 254.0 mm (10.0 in.) Height: 365.5 mm (14.4 in.)
